ZSFQ High Speed Aluminum Foil Slitting Machine


ZSFQ slitting machine is special design for slitting and rewinding materials of uneven thickness, like Aluminum Foil.

Classificar:

Products

Slitter Rewinder

Sollutions&Applications

Paper applications

Slitter rewinder

Flexible films

Slitter rewinder

Aluminum Foil

Wide-Web

Aluminum Foil

Keyword :

  • Features
  • Specifications
  • Gallery
  • Video
    • Commodity name: ZSFQ High Speed Aluminum Foil Slitting Machine
    • Commodity ID: ZSFQ-1

    ZSFQ slitting machine is special design for slitting and rewinding materials of uneven thickness, like Aluminum Foil.

    Usage:

    ZSFQ slitting machine is special design for slitting and rewinding materials of uneven thickness, like Aluminum Foil. With three individual motors synchronous control and a high rack structure, this machine can fulfill the customers who has the high demands of clean and precision for materials.

    ZSFQ slitting machine can also cut the wide Aluminum Foil into several narrow materials. It is commonly used in Aluminum Foil industrial.

    Machine features

    1. Central winding mode, flat winding surface.

    2. The main engine adopts frequency conversion speed regulation to maintain the accelerated and stable operation.

    3. The winding adopts the structure of upper and lower a and B air expansion shafts.

    4. The unwinding adopts the photoelectric automatic deviation correction system, so that the irregular materials can be cut normally.

    5. The machine shell adopts frosting and painting technology, and the color can be customized.

    6. Be equipped with rotary shear slitting knives with wool felt and high power trim edge suction fan.

    Applications:

    ZSFQ slitting Machine is suitable for many kinds of jumbo roll materials, such as Aluminum Foil.

    ZSFQ

    Packaging

    Unwinding unit and main machine part are packed separately. We use PP plastic wrapping the machine first. Then fix the machine into wooden pallet and pack them with wooden case.

    Packaging

    After-sales service

    We guarantee the quality of the main parts within 12 months. If the main parts go wrong without artificial factors within one year, we will freely provide them or maintain them for you. After one year, if you need to change parts, we will kindly provide you with the best price or maintain it in your site.

    Exhibition

    Exhibition

  • Model

    ZSFQ-1300C

    ZSFQ-1600C

    Max. Width of unwinding

    1300mm

    1600mm

    Max. diameter of unwinding

    1400mm

    1400mm

    Min. Width of slitting

    30mm

    30mm

    Max. Diameter of rewinding

    600mm

    600mm

    Speed of slitting

    80-400m/min

    80-400m/min

    Total Power

    21kw

    27kw

    Power supply

    380V/50hz

    380V/50hz

    Overall dimension

    2050*3000*1720(mm)

    2050*3300*1720 (mm)

    Weight

    3500kg

    4000kg

    Collector frame Overall dimension

    1530*1250mm

    1530*1250mm

  • ZSFQZSFQZSFQ
