WZFQ Jumbo Film Roll High-speed Slitting machine


The WZFQ model film slitting rewinding machine is an automatic tension control intelligent jumbo roll converting machine for film material rolls products processing machine.

Classificar:

Products

Slitter Rewinder

Wide-Web

Flexible Films

Sollutions&Applications

Flexible films

Slitter rewinder

Tel/ WhatsApp / WeChat:

Keywor:

  • Features
  • Specifications
  • Gallery
  • Video
    • Commodity name: WZFQ Jumbo Film Roll High-speed Slitting machine
    • Commodity ID: WZFQ-2

    The WZFQ model film slitting rewinding machine is an automatic tension control intelligent jumbo roll converting machine for film material rolls products processing machine.

    Usage:

    The WZFQ model film slitting rewinding machine is an automatic tension control intelligent jumbo roll converting machine for film material rolls products processing machine.

    Machine feature:

    1. Adopt Germany brand PLC with intelligent control system.Big size HMI operating touch screen.

    2. Three sets servo motors stable drive machine in a high speed level with frequency inverter drives.

    3. Full automatic tension control system.

    4. High precision web edge position adjustment system(EPC).

    5. Automatic loading and unloading paper rolls,saving time and labor. Loading system adopt the hydraulic lifter.

    6. The rewinding paper rolls cutting surface is smooth and flat.

    7. Automatic counting rewinding meters and automatic stop when it reach setting meters in touch screen

    8. The minimum slitting width can be 20mm,rewinding diameter can be 1000mm.

    Applications:

    WZFQ Slitter rewinder machine the high speed film slitting rewinding machine widely used to cut various width film rolls, such as BOPP, PVC, PET.

    WZFQ

    Packaging

    Unwinding unit and main machine part are packed separately. We use PP plastic wrapping the machine first. Then fix the machine into wooden pallet and pack them with wooden case.

    Packaging

    After-sales service

    We guarantee the quality of the main parts within 12 months. If the main parts go wrong without artificial factors within one year, we will freely provide them or maintain them for you. After one year, if you need to change parts, we will kindly provide you with the best price or maintain it in your site.

    Exhibition

    Exhibition

  • Model

    WZFQ-1300A

    WZFQ-1600A

    WZFQ-1800A

    Max. Width of unwinding

    1300mm

    1600mm

    1800mm

    Max. diameter of unwinding

    1400mm

    1400mm

    1400mm

    Min. Width of slitting

    30mm

    30mm

    30mm

    Max. Diameter of rewinding

    1000mm

    1000mm

    1000mm

    Speed of slitting

    ≤350m/min

    ≤350m/min

    ≤350m/min

    Total Power

    24kw

    26kw

    35kw

    Power supply

    380V/50hz

    380V/50hz

    380V/50hz

    Overall dimension

    4500*3100*1900(mm)

    4500*3800*1900(mm)

    4500*4100*1900(mm)

    Weight

    4000kg

    4500kg

    5500kg
