KFQ Full Automatic High-speed Self - adhesive labels Slitting Rewinding Machine


The KFQ model paper jumbo rolls to rolls slitting rewinding machine is a center&surface rewinding type slitter machine. It is mainly used to slit the jumbo paper rolls to small width rolls. It is widely using in Self - adhesive labels products manufacturing industry.

Classificar:

Slitter Rewinder

Self-adheresive labels

Wide-web slitter

Wide-Web

Self-adhesive labels

Keyword :

  • Features
  • Specifications
  • Gallery
  • Video
    • Commodity name: KFQ Full Automatic High-speed Self - adhesive labels Slitting Rewinding Machine
    • Commodity ID: KFQ3

    The KFQ model paper jumbo rolls to rolls slitting rewinding machine is a center&surface rewinding type slitter machine. It is mainly used to slit the jumbo paper rolls to small width rolls. It is widely using in Self - adhesive labels products manufacturing industry.

    Self - adhesive labels ——wide-web slitter

    Full Automatic High-speed Self - adhesive labels Slitting Rewinding Machine

    Description

    Usage:

    The KFQ model paper jumbo rolls to rolls slitting rewinding machine is a center&surface rewinding type slitter machine. It is mainly used to slit the jumbo paper rolls to small width rolls. It is widely using in Self - adhesive labels products manufacturing industry.

    Features:

    ● Germany brand PLC with intelligent control system.Big size operating touch screen. Control&Operating Table.

    ● Three sets servo motors stable drive machine in a high speed level.

    ● Full automatic tension control system.

    ● The frame type mechanical structure let the machine running more stable.

    ● High precision web edge position adjustment system(EPC).

    ● Automatic loading and unloading paper rolls,saving time and labor.

    ● The rewinding paper rolls surface is smooth and flat.

    ● Automatic counting rewinding meters.

    Applications:

    The paper slitting machine is suitable for cardboard paper jumbo roll to small roll.

    KFQ

    Packaging

    Unwinding unit and main machine part are packed separately. We use PP plastic wrapping the machine first. Then fix the machine into wooden pallet and pack them with wooden case.

    KFQ

    After-sales service

    We guarantee the quality of the main parts within 12 months. If the main parts go wrong without artificial factors within one year, we will freely provide them or maintain them for you. After one year, if you need to change parts, we will kindly provide you with the best price or maintain it in your site.

    Exhibition

    KFQ

  • Model

    KFQ-1300

    KFQ-1600

    KFQ-1800

    KFQ-2000

    Max. Width of unwinding

    1300mm

    1600mm

    1800mm

    2000mm

    Max. diameter of unwinding

    1700mm

    1700mm

    1700mm

    1700mm

    Min. Width of slitting

    40mm

    40mm

    40mm

    40mm

    Max. Diameter of rewinding

    1300mm

    1300mm

    1300mm

    1300mm

    Speed of slitting

    ≤400m/min

    ≤400m/min

    ≤400m/min

    ≤400m/min

    Total Power

    56kw

    56kw

    56kw

    56kw

    Power supply

    380V/50hz

    380V/50hz

    380V/50hz

    380V/50hz

    Overall dimension

    8500*3500*2700(mm)

    8500*3800*2700(mm)

    8500*4100*2700(mm)

    8500*4500*2700(mm)

    Weight

    13000kg

    14000kg

    15000kg

    17000kg
